Terraform - Azure HDInsight HBase accelerated disk write support

Originally published on an external platform.

Medium

Terraform - Azure HDInsight HBase accelerated disk write support

There has been a long-standing request in the community to support HBase Accelerated Disk Write in the terraform-provider-azurerm.

GitHub Issue: Accelerated disk write #9142

According to Azure APIs, specific flags must be set to enable accelerated writes:

{
  "properties": {
    "computeProfile": {
      "roles": [
        {
          "name": "workernode",
          "dataDisksGroups": [
            {
              "disksPerNode": 1
            }
          ]
        }
      ]
    }
  }
}

The Problem

In the Terraform provider’s schema (specifically hdinsight/schema.go), the HDInsightNodeDefinition struct defines whether disks can be specified:

type HDInsightNodeDefinition struct {
  CanSpecifyInstanceCount  bool
  MinInstanceCount         int
  MaxInstanceCount         *int
  CanSpecifyDisks          bool
  MaxNumberOfDisksPerNode  *int
  FixedMinInstanceCount    *int32
  FixedTargetInstanceCount *int32
  CanAutoScaleByCapacity   bool
  CanAutoScaleOnSchedule   bool
}

However, the plugin code had a hardcoded definition for hdInsightHBaseClusterWorkerNodeDefinition that disabled disk specification:

var hdInsightHBaseClusterWorkerNodeDefinition = HDInsightNodeDefinition{
  CanSpecifyInstanceCount: true,
  MinInstanceCount:        1,
  CanSpecifyDisks:         false, // This was the blocker
  CanAutoScaleOnSchedule:  true,
}

The Solution

To enable this feature, I modified the definition to allow disks and set the required parameters:

var hdInsightHBaseClusterWorkerNodeDefinitionWithAcceleratedWrites = HDInsightNodeDefinition{
  CanSpecifyInstanceCount: true,
  MinInstanceCount:        1,
  CanSpecifyDisks:         true, // Enabled
  CanAutoScaleOnSchedule:  true,
  MaxNumberOfDisksPerNode: utils.Int(1),
}

I also added a new configuration parameter enable_accelerated_writes to the Terraform plugin schema to give users the choice:

"enable_accelerated_writes": {
  Type:     pluginsdk.TypeBool,
  Optional: true,
  ForceNew: true,  // The resource will be re-created if this changes
  Default:  false,
},

Then, I implemented logic to decide which node definition to use based on that flag:

func decideHDInsightNodeDefinition(enableWrites bool) hdInsightRoleDefinition {
  var hbaseRoles hdInsightRoleDefinition
  if enableWrites {
    hbaseRoles = hdInsightRoleDefinition{
      HeadNodeDef:      hdInsightHBaseClusterHeadNodeDefinition,
      WorkerNodeDef:    hdInsightHBaseClusterWorkerNodeDefinitionWithAcceleratedWrites,
      ZookeeperNodeDef: hdInsightHBaseClusterZookeeperNodeDefinition,
    }
  } else {
    hbaseRoles = hdInsightRoleDefinition{
      HeadNodeDef:      hdInsightHBaseClusterHeadNodeDefinition,
      WorkerNodeDef:    hdInsightHBaseClusterWorkerNodeDefinition,
      ZookeeperNodeDef: hdInsightHBaseClusterZookeeperNodeDefinition,
    }
  }
  return hbaseRoles
}

Usage

After these changes, I was able to create an HBase Cluster with accelerated disk writes using standard Terraform HCL:

resource "azurerm_hdinsight_hbase_cluster" "example" {
  name                      = "example-hdicluster"
  resource_group_name       = azurerm_resource_group.example.name
  location                  = azurerm_resource_group.example.location
  cluster_version           = "3.6"
  enable_accelerated_writes = true
  tier                      = "Standard"

  component_version {}
  gateway {}
  storage_account {}
  roles {
    head_node {}
    worker_node {}
    zookeeper_node {}
  }
}

You can find my forked version of the Azure provider here: tfproviders/terraform-provider-azurerm.
